Auto cross feed, Longitudinal by sensor & solenoid valve and vertical axis is manual.
Continuous lubrication and Back water splash shield are standard for PFG-D4080AH.
Optimized Structure
The major parts are manufactured from high quality cast iron combined with an outstanding structural design. Major parts are stress relieved to ensure maximum rigidity, stability and machining accuracy.
Precision Spindle Design
The spindle runs in a class P4 high precision angular contact bearing, assuring run-out accuracy in 2 μm. The cartridge-type spindle is completely sealed and lubricated for long working lifetime, providing high accuracy grinding and a long service life.
Turcite-B on Slideways
The X and Z axes slideways are coated with Turcite-B for stable movement and long term accuracy.
NC Auto Down Feed System (AD5 type)(Option)
Except for the H series, the AH, and AHR models are available to equip with an optional NC auto down feed system (AD5) to become 3 axes fully automated for greatly increasing operational convenience.
NC Auto Parallel Dressing & Compensating System (Option)
The optional NC auto parallel dressing & compensating system is available to equip with an optional NC auto down feed system (AD5 type), greatly increasing the grinding efficiency.
