PFG-R400DT

INQUIRY PREV
Product Description

Surface grinders, Saddle type Optimized Structure.

Suitable for grinding Spacer, Ring, screw nut ...etc., need Concentric circles surface or need better accuracy and quality for circle work piece.



Product Feature
  • LCD touch screen panel (HMI Interface)(DT controller-Dedicated)
  • Auto down feed
  • Ø400mm Rotary table (with E.M. Chuck & controller 5A)
  • Auto. Crossing stroke adjustment by control panel switch.
  • Ball screw for cross feed
  • Quantitative lubrication system
  • Enclosed splash shield
  • Tangential speed Synchronizer (Speed of rotary table will be changed when cross feed moving)



Product Specification
SPECTIFICATEUNITPFG-R400DT
Grinding surface of table mm 400
Max. grinding surface mm 240
Max. distance center of spindle to table mm 300
[Option:400]
Total Max. safety table load kgs 170
Table guideway   V & FLAT WAY
Wheel dimension mm 355x38x127
Spindle motor HP 5
Machine net weight Kgs 1890
Packing gross weight Kgs 2200
Floor space (AxBxC) mm 1850x1900x2100
